Edge^R : The Software Solution for the Precast Concrete Industry

The EDGE^R platform provides the precast concrete industry with a comprehensive solution for project design, estimation, production, erection, and much more. EDGE^R utilizes the world’s most preeminent graphics software, Revit, to facilitate the creation of detailed 3-D models which can be translated into accurate bills of materials and shop tickets, allowing a more seamless workflow from the estimation phase through the erection phase. In combination with EDGE^ERP, EDGE^CAM, and EDGE^CLOUD, users can optimize all facets of their business.

Five Key Attributes of Edge^R

Modelling

Simple, intuitive, time-saving custom content that cuts down on human error and simplifies the reinforcing process of the model and then translates information for accurate take-offs, drawings and shop tickets.

Project Management

Through an efficient tracking process, Edge^R Ticket Manager accurately determines the number of marks and total pieces, quantifies and identifies elements that have been reinforced, tracks creation of shop tickets and identifies when a ticket is ready to be released to production.

Shop Tickets

Through the use of customizable templates, Edge^R allows the user to quickly generate shop tickets that include appropriate views, bills of materials, title block information and more.



Change Management

Changes made to the 3-D model are automatically reflected on all relevant drawings and tickets. Additionally, updated counts of such items as bricks, embeds etc. occurs.

Schedules

Edge^R provides parameters to customize detailed schedules for the whole project, portions of the project and/or one specific element of the project.



Beam modeled using EDGE^R

Beam modeled using EDGE^R

Shop ticket generated using EDGE^R for the beam to the left.

Shop ticket generated using EDGE^R for the beam to the left.

EDGE^ERP

The EDGE^ERP solution leverages the user’s model to extract information that can be directly imported into many common Enterprise Resource Planning (ERP) systems. It gathers pertinent information from all elements (such as precast elements, cast in place embeds, loose materials, lifting/handling, etc.) in the model and converts it into a file format which can then be utilized by the user or directly integrated into the user’s ERP system.

EDGE^CAM

Using the existing Revit model, EDGE^CAM makes automation of the production workflow possible. EDGE^CAM extracts information directly from the model and converts it into a file format that can be read by many automated machines. The exported file contains information about finishes, cutouts, rebar, embed placement, and much more. The practical applications include laser projection, bed plotting, automated rebar bending, automated concrete distribution, etc. Supported file formats currently include Unitechnik (UXML) versions 5.2, 6.0, and 7.0 and Progress Group (PXML) version 1.3.

EDGE^CLOUD

The cherry on the top of the cake with this amazing technology is the EdgeCloud factor. Through EdgeCloud, real time information can be provided to production and can be easily accessed on a tablet or PC allowing for seamless communication between engineering and production personnel.

EDGE^R and Virtual Reality

EDGE^R can also be used with designs for virtual reality systems. Below is a screenshot of a component designed using EDGE^R in virtual reality.

Virutal Reality Rendering.jpg

Not All Bridges Are Created Equal

An Editorial from Dan Eckenrode, PCI Gulf South Executive Director

The outrage over our nation’s crumbling infrastructure and the cry to fund new bridges and roadways is no secret. As the list of deficient bridges continues to grow, government leaders are being forced to address the issue, as it has a direct correlation to economic progress across the nation. During the recent Alabama Transportation Conference, I learned that there are over 1,200 deficient bridges in that one state alone. Some bridges have been deemed unsafe and closed altogether, while others have been downgraded in loading capacities which means heavy vehicles are no longer permitted to use them. If the bridge isn’t in your neighborhood or on your route to work, you most likely don’t give it a thought. However, when people and businesses are forced to go miles out of their way due to a closed bridge, they start to grumble.

What types of bridges are in use today?

Wooden Bridge.jpg

Wooden Bridges:  A wooden bridge might include a structure made completely from wood or a structure supported on wooden piles. Either way, wooden bridges are the number one type of failing bridge today.

Channel Bridge.jpg

Channel or “Choctaw” Bridges:  These are non-stressed concrete U channel bridges with a span of typically 26 feet that require many units to complete the span. Grout is used where the joints come together. The production of this type of bridge began in the 1960’s and is still used today with some mixed success.

Steel Bridge.jpg

Steel Bridges:  As the name suggests, this type of bridge is created from steel.

Precast Bridge.jpg

Precast-Prestressed Bridges: Bridge manufactured components that began around the same time as the previously mentioned Channel Bridges but with greater success and superior product lifespan.


Bridge Matinenance Graphic.png


The take-away is...not all bridges are created equal. In an attempt to stretch road and bridge dollars further than ever before, durability and life cycle are two repeating themes. DOT’s across the nation have come to realize that designing with precast-prestressed bridge components will yield the desired results with regard to longevity, safety and cost-effectiveness.

You can learn more about PCI certified bridge products by taking a look at the various resources below.

General Contractors Embrace Precast Concrete Systems

General Contractors Embrace Precast Concrete Systems

General contractors often have the ability to influence owners/financiers to choose particular building products when tasked with a new construction project. From the contractor’s point of view, delivering a quality project, under budget and on time is paramount to customer satisfaction. That’s a mighty big order that becomes more achievable with the use of precast concrete components and/or systems.
